1 x Texas Instruments TLV2453CDGS, Dual Op Amp, 220kHz Rail-Rail, 3V, 5V, 10-Pin - Texas Instruments
roll over the image to zoom in
£0.00
£5.99
RS 661-2176
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 50P
Texas Instruments
Texas Instruments TLV2453CDGS, Dual Op Amp, 220kHz Rail-Rail, 3 V, 5 V, 10-Pin MSOP
Product Details
Low Voltage Operational Amplifiers, TLV Series
Specifications
| Mounting Type | Surface Mount | |
| Package Type | MSOP | |
| Power Supply Type | Dual, Single | |
| Number of Channels per Chip | 2 | |
| Pin Count | 10 | |
| Typical Single Supply Voltage | 3 V, 5 V | |
| Typical Gain Bandwidth Product | 220kHz | |
| Output Type | Rail to Rail | |
| Typical Slew Rate | 0.11V/µs | |
| Minimum Operating Temperature | 0 °C | |
| Maximum Operating Temperature | +70 °C | |
| Dimensions | 3 x 3 x 1.02mm | |
| Height | 1.02mm | |
| Typical Input Voltage Noise Density | 52nV/√Hz | |
| Typical Voltage Gain | 103 dB | |
| Width | 3mm | |
| Length | 3mm |
To view the datasheet please Click Here
