1 x Texas Instruments MAX208IDB, Multichannel Line Transceiver, 5V, 24-Pin - Texas Instruments
roll over the image to zoom in
£0.00
£5.99
RS 660-8596
Unit Quantity:
1
Unit Type:
Unit
Location:
BRA 4 ORANGE
Texas Instruments
Texas Instruments MAX208IDB, Multichannel Line Transceiver, RS-232 4-TX 4-RX, 5 V, 24-Pin SSOP
Product Details
RS-232 Line Transceivers, Multi-channel, Texas Instruments
RS-232 Line Drivers and Receivers
Specifications
| Number of Transmitters | 4 | |
| Package Type | SSOP | |
| Mounting Type | Surface Mount | |
| Pin Count | 24 | |
| Number of Receivers | 4 | |
| Typical Single Supply Voltage | 5 V | |
| Data Rate | 120kbps | |
| Interface Standards | RS-232 | |
| Transmitter Signal Type | Single Ended | |
| Receiver Signal Type | Single Ended | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +85 °C | |
| Number of Receivers per Line | 1 | |
| Number of Drivers per Line | 1 | |
| Power Supply Type | Single | |
| Dimensions | 8.2 x 5.3 x 1.95mm | |
| Length | 8.2mm | |
| Height | 1.95mm | |
| Width | 5.3mm |
To view the datasheet please Click Here
Nichicon Aluminium Polymer Capacitor 330μF 2.5 V dc 6.3mm Through Hole LS Series Lifetime 5000h
Product Details
LS Series Solid Electrolytic Radial
Solid Radial 105°C
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Capacitance | 330 µF | |
| Technology | Polymer | |
| Voltage | 2.5 V dc | |
| Dimensions | 6.3 (Dia.) x 9mm | |
| Height | 9mm | |
| Diameter | 6.3mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 2.5mm | |
| Construction | Radial | |
| Series | LS | |
| Terminal Type | Through Hole | |
| Lifetime | 5000h | |
| Leakage Current | 500 μA | |
| Board Level Components | Y | |
| Lead Diameter | 0.6mm | |
| Ripple Current | 4.8A | |
| Tolerance Minus | -20% | |
| Tolerance | ±20% | |
| Tolerance Plus | +20% | |
| Equivalent Series Resistance | 8mΩ |
TDK 4.7μF Multilayer Ceramic Capacitor MLCC 25 V dc ±10% X7R Dielectric 1210 Surface Mount Max. Op. Temp. +125°C
Product Details
TDK Type 1210 Series C3225
MLCC C Series is a monolithic structure that ensures superior mechanical strength and reliability.
High capacitance has been achieved through precision technologies that enable the use of multiple thinner ceramic dielectric layers.
Features and Benefits
Low ESL and excellent frequency characteristics allow for a circuit design that closely conforms to theoretical valuesLow self-heating and high ripple resistance due to low ESR
Applications:
• General Electronic Equipment• Mobile Communication Equipment
• Power Supply Circuit
• Office Automation Equipment
• TV, LED displays
• Servers, PCs, Notebooks, Tablets"
1210 Range
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Capacitance | 4.7 µF | |
| Voltage | 25 V dc | |
| Package/Case | 1210 | |
| Dielectric | X7R | |
| Tolerance | ±10% | |
| Dimensions | 3.2 x 2.5 x 2mm | |
| Length | 3.2mm | |
| Depth | 2.5mm | |
| Height | 2mm | |
| Series | C | |
| Tolerance Minus | -10% | |
| Tolerance Plus | +10% | |
| Temperature Coefficient | ±15% | |
| Terminal Type | Surface Mount | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +125°C |
