1 x TE Connectivity Voltage Compression Load Cell 226.796kg, 5.25V, 6.7V, 10V - TE Connectivity
roll over the image to zoom in
£0.00
£139.99
RS 893-7408
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 56R
TE Connectivity
TE Connectivity Voltage Compression Load Cell 226.796kg, 5.25 V, 6.7 V, 10 V
- BMUK Part # :-893-7408
- BrandTE Connectivity
- Mfr. Part No.FC2311-0000-0500-L
-
- You will get 1 Load Cell
Product Details
TE Connectivity FC23 Series Compression Load Cells
TE Connectivity’s MEAS FC23 series consists of robust load cells that act as high compression force sensors. Thermally compensated for changes in zero and span regarding temperatures, FC23 load cells offer normalised zero and span for interchangeability. Utilising Microfused™ technology and removing the need for age-sensitive epoxies, the FC23 load cells have an essentially unlimited life cycle expectancy, superior resolution and high over-range capabilities when operated at low strains.
Suitable applications include load and compression sensing, robotics end-effectors, pumps, hoist and winch loads, weighing, batch weighing, variable force control and assembly line force measurement.
Interchangeable
Long cycle life expectancy
High level of reliability
Fast response time
Low deflection
High over-range capability
Specifications
| Force Measured | Compression | |
| Force/ Load Measurement Range | 226.796kg | |
| Maximum Excitation Voltage | 5.25 V, 6.7 V, 10 V | |
| Output At Rated Load | 20mV/V | |
| Terminal Type | Wire Lead | |
| Overall Height | 10.2mm | |
| Overall Width | 31.75mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Standards Met | CE Approval, RoHS Compliant | |
| Measurement Mechanism | Piezoelectric | |
| Output Type | Voltage | |
| Hysteresis | 1% |
