TE Connectivity AMP-LATCH 622 Series, Right Angle Cable Mount IDC Connector Plug, 34 Way, 2 Row, 2.54mm Pitch
- BMUK Part # :-462-155
- BrandTE Connectivity
- Mfr. Part No.1658525-2
-
- You will get 1 Connector
Product Details
TE Connectivity AMP-Latch 622 Series 2.54 x 2.54mm IDC DIP Plug Ribbon Cable Connectors
AMP-Latch 622 series IDC DIP plug ribbon cable connectors with 2.54 x 2.54mm centres and single slot, flat, tuning fork style IDC contacts. These IDC DIP plug ribbon cable connectors are made from blue UL 94V-0 rated glass-filled thermoplastic and are for use with 26 to 28 AWG solid or stranded PVC insulated ribbon cable.
Designed so the cable can be crimped before or after the connector is soldered to the PCB
Rugged glass reinforced thermoplastic
Height 8.97mm
Suitable universal hand tool, stock no. 462-975 & die, stock no. 463-013
TE Connectivity AMP-Latch IDC Ribbon Cable Connectors
Specifications
| Number of Contacts | 34 | |
| Number of Rows | 2 | |
| Gender | Male | |
| Pitch | 2.54mm | |
| Mounting Type | Cable Mount | |
| Body Orientation | Right Angle | |
| Termination Method | IDC | |
| Current Rating | 1A | |
| Contact Plating | Tin | |
| Series | AMP-LATCH 622 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +125°C | |
| Contact Material | Beryllium Copper | |
| Housing Material | Thermoplastic |
