1 x TDK-Lambda KWD 15 15 15, 15W 2 Output, Switch Mode Power Supply ±15V ±520mA - TDK-Lambda
roll over the image to zoom in
£0.00
£96.99
RS 217-6430
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 16A
TDK-Lambda
TDK-Lambda KWD 15 15 15, 15W, 2 Output, Embedded Switch Mode Power Supply (SMPS), ±15V, ±520mA
- BMUK Part # :-217-6430
- BrandTDK-Lambda
- Mfr. Part No.KWD 15 15 15
- You will get 1 Switch Mode Power Supply
Product Details
TDK-Lambda, PCB Mount, Encapsulated, Switch Mode AC-DC Power Supply - KW Series
Small, lightweight & universal input
Input 85-265Vac, ideal for small systems and instrumentation applications worldwide
Overvoltage/Overcurrent protection
Plastic case complies to UL94V-0
Conducted noise (EMI) VCCI-II and FCC-B (will meet VDE-B with external capacitor)
| Dimensions | ||||||||
| Type | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | Wt. (g) |
| KW5 | 45 | 55 | 20.5 | 17.5 | 20 | 47 | 4 | 75 |
| KW10 | 45 | 64 | 20.5 | 17.5 | 20 | 54 | 6 | 100 |
| KW15 | 48 | 70 | 23.5 | 20 | 23 | 62 | 4 | 150 |
| External capacitor value required to meet VDE-B: | ||
| 5W units | 0.22μf | 250Vac (class ´2) |
| 10/15W units | 0.33μf | 250Vac (class ´2) |
| Input frequency 47 - 440Hz | ||
| Isolation 3kVac input/output, 2kV input/ground, 500Vdc output/FG |
Note
MTBF to MIL-HDBK-217D.
Should not be run under sustained short circuit conditions.
Approvals
TUV, UL recognised, CSA certified
Standards
IEC 950, EN60950
Switch Mode - TDK-Lambda
Specifications
| Output Voltage | ±15 V | |
| Output Current | ±520mA | |
| Power Rating | 15W | |
| Input Voltage | 85 → 265 V ac, 110 → 340 V dc | |
| Number of Outputs | 2 | |
| Package Type | Encapsulated | |
| Length | 70mm | |
| Width | 48mm | |
| Depth | 23.5mm | |
| Ripple And Noise | 150mV Pk-Pk | |
| Load Regulation | ±0.8% | |
| Line Regulation | ±0.4% | |
| Minimum Temperature | -10°C | |
| Maximum Temperature | +70°C | |
| MTBF | 80866h | |
| Efficiency | 73% | |
| Weight | 150g |
For a Specification PDF Please CLICK HERE
