1 x TDK-Lambda HWS300-24/ME, 336W, 1 Output, Switch Mode Power Supply, 24V, 14A - TDK-Lambda
roll over the image to zoom in
£0.00
£275.99
RS 200-285
Unit Type:
Unit
TDK-Lambda
TDK-Lambda 336W, 1 Output, Embedded Switch Mode Power Supply (SMPS), 24V, 14A
- BMUK Part # :-200-285
- BrandTDK-Lambda
- Mfr. Part No.HWS300-24/ME
- You will get 1 Switch Mode Power Supply
Product Details
50W to 300W, Universal Input, Single Output, Medical Approved, HWS-50-300/ME Series
Exceptionally compact, requires typically 60% less space than previous generation products
Medical approvals EN 60601-1, UL 60601-1
Leakage current less than 500μA
LED indicator for power on
Easy installation - screw terminals
Adjustable output voltage (±20%)
Power factor correction to EN 61000-3-2
EMC meets EN 55022-B, FCC-B
Over-voltage and over-current protection
Open frame construction 50 to 150W
300W is enclosed with built-in fan
Note
Dimensions quoted exclude terminal block. Peak load for 10ms max on time, 35% duty cycle. De-rate above 50°C.
Approvals
UL recognised, CSA
Standards
EN 60601-1, UL 60601-1, CSA-C22.2 No. 6011-M90
Switch Mode - TDK-Lambda JWS, JWT, SC120, HWS Series
Specifications
| Output Voltage | 24 V | |
| Output Current | 14A | |
| Power Rating | 336W | |
| Input Voltage | 85 → 265 V ac, 120 → 330 V dc | |
| Number of Outputs | 1 | |
| Package Type | Enclosed | |
| Length | 6.5in | |
| Width | 3.23in | |
| Depth | 2.4in | |
| Ripple And Noise | 150mV | |
| Load Regulation | 144mV | |
| Line Regulation | 96mV | |
| Minimum Temperature | -10°C | |
| Maximum Temperature | +70°C | |
| Efficiency | 86% | |
| Weight | 1000g |
For a Specification PDF Please CLICK HERE
Thank you for looking, if you have any questions please ask or call us.
