1 x STMicroelectronics VN750PT-E MOSFET Power Driver 6A, 5.5-36V, Non-Inverting - STMicroelectronics
roll over the image to zoom in
£0.00
£14.99
RS 445-614
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 51A
STMicroelectronics
STMicroelectronics VN750PT-E MOSFET Power Driver 6A, 5.5 → 36 V, Non-Inverting, PPAK 5-Pin
- BMUK Part # :-445-614
- BrandSTMicroelectronics
- Mfr. Part No.VN750PT-E
-
- You will ONE Power Driver IC
Product Details
Power ICs, High-Side Power Switches, STMicroelectronics
High-side switches can safely drive high currents in resistive, inductive and capacitive grounded loads. Designed to work in the harsh automotive environment they requires both robust, low on-resistance power switch and accurate analogue circuitry for diagnostic, protection and control functions.
Intelligent Power Switches, STMicroelectronics
Specifications
| Number of Drivers | 1 | |
| Minimum Operating Supply Voltage | 5.5 V | |
| Maximum Operating Supply Voltage | 36 V | |
| Driver Configuration | Non-Inverting | |
| Mounting Type | Surface Mount | |
| Peak Output Current | 6A | |
| Number of Outputs | 1 | |
| Driver Type | High Side | |
| Package Type | PPAK | |
| Pin Count | 5 | |
| Input Logic Compatibility | CMOS | |
| Minimum Operating Temperature | -40 °C | |
| Height | 2.4mm | |
| Length | 6.6mm | |
| Dimensions | 6.6 x 6.2 x 2.4mm | |
| Maximum Operating Temperature | +150 °C | |
| Width | 6.2mm |
To view the datasheet please Click Here
