1 x STMicroelectronics STF57N65M5 N-channel MOSFET Transistor, 42A, 710V, 3-Pin - STMicroelectronics
roll over the image to zoom in
£0.00
£8.99
RS 783-3002
Unit Quantity:
1
Unit Type:
Unit
STMicroelectronics
STMicroelectronics STF57N65M5 N-channel MOSFET Transistor, 42 A, 710 V, 3-Pin TO-220FP
- BMUK Part # :-783-3002
- BrandSTMicroelectronics
- Mfr. Part No.STF57N65M5
-
- You will get 1 Transistor
Product Details
N-channel MDmesh™ M5 Series, STMicroelectronics
The MDmesh M5 power MOSFETs are optimised for high-power PFC and PWM topologies. Main features include a low on-state losses per silicon area combined with low gate charge. They are designed for energy-conscious, compact and reliable hard switching applications, such as solar power converters, power supplies for consumer products and electronic lighting controls.
MOSFET Transistors, STMicroelectronics
Specifications
| Channel Type | N | |
| Maximum Continuous Drain Current | 42 A | |
| Maximum Drain Source Voltage | 710 V | |
| Maximum Drain Source Resistance | 0.063 Ω | |
| Maximum Gate Threshold Voltage | 5V | |
| Minimum Gate Threshold Voltage | 3V | |
| Maximum Gate Source Voltage | ±25 V | |
| Package Type | TO-220FP | |
| Mounting Type | Through Hole | |
| Transistor Configuration | Single | |
| Pin Count | 3 | |
| Channel Mode | Enhancement | |
| Category | Power MOSFET | |
| Maximum Power Dissipation | 40 W | |
| Length | 10.4mm | |
| Dimensions | 10.4 x 4.6 x 16.4mm | |
| Typical Turn-Off Delay Time | 73 ns | |
| Width | 4.6mm | |
| Number of Elements per Chip | 1 | |
| Transistor Material | Si | |
| Typical Turn-On Delay Time | 73 ns | |
| Typical Gate Charge @ Vgs | 98 nC @ 10 V | |
| Typical Input Capacitance @ Vds | 4200 pF@ 10 V | |
| Height | 16.4mm | |
| Maximum Operating Temperature | +150 °C |
