1 x STMicro STP28NM50N N-channel MOSFET, 21A, 500V MDmesh, 3-Pin TO-220 - STMicroelectronics
roll over the image to zoom in
£0.00
£8.99
RS 761-0092
Unit Quantity:
1
Unit Type:
Unit
Location:
ES-5L
STMicroelectronics
STMicroelectronics STP28NM50N N-channel MOSFET, 21 A, 500 V MDmesh, 3-Pin TO-220
- BMUK Part # :-761-0092
- BrandSTMicroelectronics
- Mfr Part No.STP28NM50N
-
- You will get 1 Transistor
Product Details
N-Channel MDmesh™, 500V, STMicroelectronics
MOSFET Transistors, STMicroelectronics
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
10.4mm
Transistor Configuration
Single
Typical Turn-On Delay Time
13.6 ns
Brand
STMicroelectronics
Typical Turn-Off Delay Time
62 ns
Maximum Continuous Drain Current
21 A
Package Type
TO-220
Maximum Power Dissipation
150 W
Series
MDmesh
Mounting Type
Through Hole
Width
4.6mm
Maximum Gate Threshold Voltage
4V
Height
15.75mm
Minimum Gate Threshold Voltage
2V
Maximum Drain Source Resistance
158 mΩ
Maximum Drain Source Voltage
500 V
Pin Count
3
Dimensions
10.4 x 4.6 x 15.75mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
50 nC @ 10 V
Transistor Material
Si
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
1735 pF@ 25 V
Channel Type
N
Maximum Gate Source Voltage
-25 V, +25 V
