1 x Siemens Overload Relay, Sirius Classic, Direct Contactor, 7-10A, 10A, 4kW - Siemens
roll over the image to zoom in
£0.00
£54.74
RS 243-6928
Unit Quantity:
1
Unit Type:
Unit
Location:
ES-3B
Siemens
Overload Relay, 7 → 10 A, 10 A, 4 kW
- BMUK Part # :- 243-6928
- BrandSiemens
- Mfr. Part No.3RU11161JB0
- You will get 1 Overload Relay
Product Details
Overload Relays – 3RU11 Range
Trip Class 10
Coil and auxiliary contact repeat terminals
Trip fault indication
Manual/auto reset
Single phase differential protection
Temperature compensated trip: -20°C to +60°C
Note
The width and height measurements of the overload relays are dependent on the contactor they are used on.
Approvals
UL, CSA
Standards
IEC947, VDE0990, EN60947
Specifications
| FLC Motor Rating | 7 → 10 A | |
| Contact Current Rating | 10 A | |
| Pole Configuration | 3P | |
| Range | Sirius Classic | |
| Contact Voltage Rating | 690 V ac | |
| Mounting Style | Direct Contactor | |
| Series | 3RU | |
| Normal State Configuration | NO/NC | |
| Number Of Auxiliary Contacts | 2 | |
| Power Rating | 4 kW | |
| Terminal Type | Screw | |
| Reset Method | Automatic, Manual | |
| Depth | 78mm | |
| Dimensions | 87 x 45 x 78 mm | |
| Maximum Operating Temperature | +70°C | |
| CAD Drawing | 3D CAD Model | |
| Minimum Operating Temperature | -20°C | |
| Length | 87mm | |
| Width | 45mm | |
| Operating Temperature Range | -20 → +70 °C |
