1 x Semikron SKM150GB123D IGBT Transistor Module 150A 1200V Half Bridge 2 IGBT's - Semikron
roll over the image to zoom in
£0.00
£144.99
RS 214-4051
Unit Quantity:
1
Unit Type:
Unit
Location:
ES Shelf
Semikron
Semikron SKM150GB123D, D 56 Series IGBT Module, 150 A max, 1200 V, Screw Mount
- BMUK Part # :-214-4051
- BrandSemikron
- Mfr. Part No.SKM150GB123D
- You will get 1 IGBT Transistor Module
Product Details
Dual IGBT Modules
A range of SEMITOP® IGBT modules from Semikron incorporating two series-connected (half bridge) IGBT devices. The modules are available in a wide range of voltage and current ratings and are suitable for a variety of power switching applications such as AC inverter motor drives and Uninterruptible Power Supplies.
Compact SEMITOP® package
Suitable for switching frequencies up to 12kHz
Insulated copper baseplate using Direct Bonded Copper technology
IGBT Modules, Semikron
The Insulated Gate Bipolar Transistor or IGBT is a three-terminal power semiconductor device, noted for high efficiency and fast switching. The IGBT combines the simple gate-drive characteristics of the MOSFETs with the high-current and low–saturation-voltage capability of bipolar transistors by combining an isolated gate FET for the control input, and a bipolar power transistor as a switch, in a single device.
Specifications
| Configuration | Series | |
| Maximum Continuous Collector Current | 150 A | |
| Maximum Collector Emitter Voltage | 1200 V | |
| Maximum Gate Emitter Voltage | ±20V | |
| Channel Type | N | |
| Mounting Type | Screw Mount | |
| Package Type | D 56 | |
| Pin Count | 3 | |
| Dimensions | 106.4 x 61.4 x 30.5mm | |
| Height | 30.5mm | |
| Length | 106.4mm | |
| Maximum Operating Temperature | +150 °C | |
| Width | 61.4mm | |
| Minimum Operating Temperature | -40 °C |
For a Specification PDF Please CLICK HERE
Thank you for looking, if you have any questions please ask or call us.
