1 x Semelab 2N2369ACSM NPN Transistor, 200mA, 15V, 3-Pin LCC 1 - Semelab

roll over the image to zoom in

£0.00
£30.99
RS 738-7581
Earn0
reward points

In stock: 2

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    ES-10A


    Semelab

    Semelab 2N2369ACSM NPN Transistor, 200 mA, 15 V, 3-Pin LCC 1

    • BMUK Part # :-738-7581
    • BrandSemelab
    • Mfr Part No.2N2369ACSM
    •  Semelab
    •
    • You will get 1 Transistor

    Semelab 2N2369ACSM NPN Transistor, 200 mA, 15 V, 3-Pin LCC 1
    Product Details

    Small Signal Transistors, Semelab







    Bipolar Transistors, Semelab

    Specifications

    Maximum Collector Emitter Saturation Voltage
    0.5 V
    Maximum Operating Temperature
    +200 °C
    Number of Elements per Chip
    1
    Maximum Base Emitter Saturation Voltage
    1.6 V
    Length
    3.05mm
    Maximum Collector Base Voltage
    40 V
    Transistor Configuration
    Single
    Brand
    Semelab
    Maximum Collector Emitter Voltage
    15 V
    Package Type
    LCC 1
    Maximum Power Dissipation
    360 mW
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -65 °C
    Width
    2.54mm
    Maximum DC Collector Current
    200 mA
    Transistor Type
    NPN
    Height
    1.4mm
    Pin Count
    3
    Dimensions
    3.05 x 2.54 x 1.4mm
    Maximum Emitter Base Voltage
    4.5 V
    Minimum DC Current Gain
    40
