1 x RS Pro 5 Way Cable Mount XLR Connector, Male, Silver Plated Contacts 250V ac - RS Pro
roll over the image to zoom in
£0.00
£7.99
RS 457-897
Unit Quantity:
1
Unit Type:
Unit
Location:
ES-6B
RS Pro
RS Pro 5 Way Cable Mount XLR Connector, Male, Silver Plated Contacts, 250 V ac
- BMUK No.457-897
- BrandRS Pro
- You will get 1 Connector
Product Details
RS Pro Cable Mount Connectors with Backshell
From RS Pro, these Multipole audio/video connectors are manufactured for professional use. The “AXR”/”XLR” compatible connectors are precision made with zinc diecast bodies and silver-plated, solid brass turned contacts. A huge benefit of these connectors is the “squeeze” release clip, which enables plugs and sockets to be unplugged quickly with a simple push-down device. Wiring and assembly are also simple operations and a collet arrangement can accommodate cable diameters ranging from 2.8 mm to 8.0 mm to provide an effective cable grip. All models are highly reliable and excellent quality.
RS XLR Connectors
Specifications
Gender
Male
Voltage Rating
250 V ac
Contact Material
Brass
Brand
RS Pro
Minimum Operating Temperature
-30°C
Maximum Operating Temperature
+80°C
Housing Material
Zinc
Contact Plating
Silver
Termination Method
Solder
Colour
Natural
Current Rating
7.5A
Mounting Type
Cable Mount
Number Of Contacts
5
Body Orientation
Straight
