1 x Renesas Electronics R5F563TCDDFA, 32bit RX Microcontroller, 100MHz, 120-Pin - Renesas Electronics

roll over the image to zoom in

£0.00
£34.99
RS 789-3225
Earn0
reward points

In stock: 16

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS-LB 6E


    Renesas Electronics

    Renesas Electronics R5F563TCDDFA, 32bit RX Microcontroller, 100MHz, 384 kB Flash, 120-Pin LQFP



    • BMUK Part Number. 789-3225
    • BrandRenesas Electronics
    • Mfr Part No.R5F563TCDDFA
    •
    •
    • You will get 1 Microcontroller












    Product Details

    RX63T Microcontrollers

    The RX63T family of 32-bit microcontrollers features 100MHz operation and a wide range of peripherals making it ideal for motor control.






    RX Family Microcontrollers, Renesas Electronics

    Specifications


    Maximum Operating Temperature
    +85 °C
    ADC Resolution
    10 bit, 12 bit
    Program Memory Type
    Flash
    Program Memory Size
    384 kB
    Length
    15.9mm
    Number of ADC Units
    4
    Device Core
    RX
    Number of UART Channels
    5
    Instruction Set Architecture
    CISC Harvard
    ADCs
    20-ch x 10-bit, 4-ch x 12-bit, 8-ch x 12-bit
    Brand
    Renesas Electronics
    Package Type
    LQFP
    ADC Channels
    4, 8, 20
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -40 °C
    Data Bus Width
    32bit
    Number of PCI Channels
    0
    Width
    15.9mm
    Maximum Number of Ethernet Channels
    0
    Family Name
    RX
    USB Channels
    1
    Height
    1.4mm
    RAM Size
    32 kB
    Timers
    4 x 16 bit, 8 x 16 bit
    Number of CAN Channels
    1
    Pin Count
    120
    Number of USART Channels
    0
    Dimensions
    15.9 x 15.9 x 1.4mm
    Number of Timers
    3
    Number of Ethernet Channels
    0
    Number of I2C Channels
    2
    Number of SPI Channels
    2
    Maximum Frequency
    100MHz
    Timer Resolution
    16bit
    Typical Operating Supply Voltage
    4 → 5.5 V
    Number of LIN Channels
    0
