1 x Recom Isolated DC-DC Converter RP12-4812DAW, Vin 18-75V dc, Vout ±12V dc - Recom
roll over the image to zoom in
£0.00
£53.99
RS 164-296
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 33C
Recom
Recom Through Hole Isolated DC-DC Converter, Vin 18 → 75 V dc, I/O isolation 1600V dc, Vout ±12V dc
BMUK Part # :-164-296BrandRecomMfr. Part No.RP12-4812DAW
Product Details
Recom 12W Single/Dual Output Regulated Isolated DC-DC Converter - RP12-AW Series
High power density
Ultra-wide 4:1 input voltage range
Regulated outputs
1.6kV input / output isolation
Pi input filter, meets EN 55022 Class A/B with external filter
Remote On/Off Control
Under voltage, over voltage (single), over load and short circuit protection
Shielded metal case with insulated baseplate
24-pin DIP with industry standard pin-out
Connection Data
| Pin | Single Output | Dual Output |
| 1 | Remote on/off | Remote on/off |
| 2 | -Vin | -Vin |
| 3 | -Vin | -Vin |
| 9 | NC | Common |
| 11 | NC | -V out |
| 14 | +V out | +Vout |
| 16 | -V out | Common |
| 22 | +Vin | +Vin |
| 23 | +Vin | +Vin |
Note
Operating temperature is without de-rating.
Recom - 7.5W to 15W
Specifications
| Output Voltage | ±12V dc | |
| Input Voltage Range | 18 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 1600V dc | |
| Output Current | ±0.5A | |
| Mounting Type | Through Hole | |
| Number of Outputs | 2 | |
| Package | DIP | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +65°C | |
| Board Level Components | Y | |
| Series | RP12 AW | |
| Length | 31.8mm | |
| Depth | 10.2mm |
