1 x Recom Isolated DC-DC Converter RP12-2415SAW, Vin 9-36V dc, Vout 15V dc - Recom
roll over the image to zoom in
£0.00
£43.99
RS 843-9478
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 26C
Recom
Recom Isolated DC-DC Converter, Vin 9 → 36 V dc, Vout 15V dc, I/O isolation 1600V dc
- BMUK Part # :-843-9478
- BrandRecom
- Mfr. Part No.RP12-2415SAW
- You will get 1 DC-DC Converter
Product Details
Recom 12W Single/Dual Output Regulated Isolated DC-DC Converter - RP12-AW Series
High power density
Ultra-wide 4:1 input voltage range
Regulated outputs
1.6kV input / output isolation
Pi input filter, meets EN 55022 Class A/B with external filter
Remote On/Off Control
Under voltage, over voltage (single), over load and short circuit protection
Shielded metal case with insulated baseplate
24-pin DIP with industry standard pin-out
| Connection Data | ||
| Pin | Single Output | Dual Output |
| 1 | Remote on/off | Remote on/off |
| 2 | -Vin | -Vin |
| 3 | -Vin | -Vin |
| 9 | NC | Common |
| 11 | NC | -V out |
| 14 | +V out | +Vout |
| 16 | -V out | Common |
| 22 | +Vin | +Vin |
| 23 | +Vin | +Vin |
Note
Operating temperature is without de-rating.
Recom - 7.5W to 15W
Specifications
| Output Voltage | 15V dc | |
| Input Voltage Range | 9 → 36 V dc | |
| Input Voltage Nominal | 24 V dc | |
| Isolation Voltage | 1600V dc | |
| Output Current | 800mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 1 | |
| Package | DIP | |
| Efficiency | 86% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +65°C | |
| Load Regulation | ±0.5% | |
| Line Regulation | ±0.2% | |
| Ripple And Noise | 85mV Pk-Pk | |
| Weight | 18g | |
| Series | RP12 AW | |
| Length | 31.8mm | |
| Depth | 10.2mm | |
| Width | 20.3mm |
For a Specification PDF Please CLICK HERE
