1 x Recom Isolated DC-DC Converter REC10-4805D/H2/M, Vin 36-75V dc, Vout ±5V dc - Recom
roll over the image to zoom in
£0.00
£46.99
RS 777-3499
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 26H
Recom
Recom Isolated DC-DC Converter, Vin 36 → 75 V dc, Vout ±5V dc
- BMUK Part # :-777-3499
- BrandRecom
- Mfr. Part No.REC10-4805D/H2/M
-
- You will get 1 DC-DC Converter
Product Details
Recom 10W Single/Dual Output Regulated Isolated DC-DC Converter - REC10-M Series
The Recom REC10/M is a series of isolated DC/DC converters. This Regulated converter offers single and dual outputs in a small package. The REC10/M can deliver 150% rated power for short periods of time, to cope with applications with large capacitive loads or high start up currents. This Recom DC/DC regulated converter comes with remote control on/off as standard and is suitable for high power industrial applications.
10W in 2” x 1” Package
2kVdc and 3kVdc Isolation Options
2:1 or 4:1 input Voltage Range
Continuous Short Circuit Protection (power limiting)
Synchronous Rectification
Full SMD internal design
Remote Control Pin
Efficiency up to 87%
Standards
EN-60950-1, UL-60950-1
Recom - 7.5W to 15W
Specifications
| Output Voltage | ±5V dc | |
| Input Voltage Range | 36 → 75 V dc | |
| Input Voltage Nominal | 48 V dc | |
| Isolation Voltage | 1000 (Rated for 1 Minute) V ac, 2000 (Tested for 1 Second) V dc | |
| Output Current | ±1A | |
| Mounting Type | Through Hole | |
| Number of Outputs | 2 | |
| Package | 1 x 2 in | |
| Efficiency | 82 → 83% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +81°C | |
| Load Regulation | ±1.2% | |
| Line Regulation | ±0.3% | |
| Weight | 27g | |
| Depth | 10.2mm | |
| Length | 50.8mm | |
| MTBF | >1000 x 10³ (+25 °C) h, >250 x 10³ (+71 °C) h | |
| Ripple And Noise | 100mV Pk-Pk |
For a Specification PDF Please CLICK HERE
