1 x Recom DC-DC Converter REC3.5-1215DRW/R10/A Vin 9-18Vdc 10000V dc Vout ±15Vdc - Recom
roll over the image to zoom in
£0.00
£76.99
RS 843-9302
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 32S AND TS-BRA-8M
Recom
Recom Through Hole Isolated DC-DC Converter, Vin 9 → 18 V dc, I/O isolation 10000V dc, Vout ±15V dc
BMUK Part # :-843-9302BrandRecomMfr. Part No.REC3.5-1215DRW/R10/A
Product Details
Recom 3.5W DIP Single/Dual Output Medical Approved Regulated Isolated DC-DC Converter - REC3-R10/A Series
Regulated output
10kVdc reinforced isolation
Industry standard DIP24 package
Continuous short circuit protection
Wide range input 2:1
Efficiency up to 86%
Note
Operating temperature is without derating.
MTBF to MIL-HDBK 217F (+25°C).
Approvals
CB, CSA
Standards
IEC60601-1, CSA C22.2 601-1, CSA C22.2 No. 60950-1-03, UL 60601-1, UL 60950-1
Recom - DIP 1W to 10W
Specifications
| Output Voltage | ±15V dc | |
| Input Voltage Range | 9 → 18 V dc | |
| Input Voltage Nominal | 12 V dc | |
| Isolation Voltage | 10000V dc | |
| Output Current | ±117mA | |
| Mounting Type | Through Hole | |
| Number of Outputs | 2 | |
| Package | DIP | |
| Efficiency | 83% | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Load Regulation | ±0.6% | |
| Line Regulation | ±0.3% | |
| Board Level Components | Y | |
| Ripple And Noise | 150mV Pk-Pk | |
| Series | REC3.5 | |
| MTBF | 1206 x 10³h | |
| Width | 20.3mm | |
| Depth | 10.2mm | |
| Length | 32mm | |
| Weight | 14g |
