1 x Recom 5W, 1 Output, Embedded Switch Mode Power Supply RAC05-24SB, 24V dc - Recom
roll over the image to zoom in
£0.00
£75.99
RS 193-317
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 7A
Recom
Recom 5W, 1 Output, Embedded Switch Mode Power Supply (SMPS) RAC05-24SB, 24V dc, 230mA
- BMUK Part # :-193-317
- BrandRecom
- Mfr. Part No.RAC05-24SB
-
- You will get 1 Switch Mode Power Supply
Product Details
Recom 5W & 10W, PCB Mount, Encapsulated, Switch Mode AC-DC Power Supply - RAC-B Series
Ultra compact, fully encapsulated power supplies
Plastic case UL94-V0 rated
Solder pins for PCB mounting
Universal input 90-264Vac or 120-370Vdc
EMI compliance to EN 55022 Class B
Short circuit, overload and overvoltage protection
| Connection Data | |
| Pin | Single Output |
| 1 | AC in (N) |
| 2 | AC in (L) |
| 3 | +V out |
| 4 | - V out |
Note
Derate output power above 50°C.
Approvals
UL recognised
Standards
UL 60950-1
Switch Mode - Recom, RAC Series
Specifications
| Output Voltage | 24 V dc | |
| Output Current | 230mA | |
| Power Rating | 5W | |
| Input Voltage | 90 → 264V ac | |
| Number of Outputs | 1 | |
| Package Type | Encapsulated | |
| Length | 50.8mm | |
| Width | 25.4mm | |
| Depth | 15.16mm | |
| Ripple And Noise | ±0.2 %, ±0.5 % | |
| Load Regulation | ±0.5% | |
| Line Regulation | ±0.3% | |
| Minimum Temperature | -25°C | |
| Maximum Temperature | +70°C | |
| Efficiency | 77% | |
| MTBF | 360000h | |
| Weight | 30g |
