1 x Panasonic Aluminium Electrolytic Capacitor EETEE2E591JJ, 590uF 250V dc - Panasonic
roll over the image to zoom in
£0.00
£4.99
RS 743-5425
Unit Quantity:
1
Unit Type:
Unit
Panasonic
Panasonic Aluminium Electrolytic Capacitor 590μF 250 V dc 25mm Through Hole EE SNAP IN Series Lifetime 3000h
- BMUK Part # :-743-5425
- BrandPanasonic
- Mfr. Part No.EETEE2E591JJ
-
- You will get 1 Capacitor
Product Details
EE Series
Highly reliable capacitors with high ripple currents and low profile
10mm printed circuit board pitch
Suitable for switched mode power supplies
2-Pin 105°C
Specifications
| Capacitance | 590 µF | |
| Technology | Electrolytic | |
| Voltage | 250 V dc | |
| Dimensions | 25 (Dia.) x 40mm | |
| Height | 40mm | |
| Diameter | 25mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 10mm | |
| Construction | Snap-In | |
| Series | EE SNAP IN | |
| Lead Diameter | 1.5mm | |
| Ripple Current | 2.3A | |
| Tolerance Minus | -20% | |
| Tolerance | ±20% | |
| Tolerance Plus | +20% | |
| Terminal Type | Through Hole | |
| Board Level Components | Y | |
| Lifetime | 3000h | |
| Leakage Current | 3√CV μA |
