1 x Panasonic Aluminium Electrolytic Capacitor EETED2W820CA, 82uF 450V dc - Panasonic
roll over the image to zoom in
£0.00
£7.49
RS 575-349
Unit Quantity:
1
Unit Type:
Unit
Location:
CAPACITOR MAIN SHELF
Panasonic
Panasonic Aluminium Electrolytic Capacitor 82μF 450 V dc 25mm Through Hole ED SNAP IN Series Lifetime 3000h +105°C
- BMUK Part # :-575-349
- BrandPanasonic
- Mfr. Part No.EETED2W820CA
- You will get 1 Capacitor
Image representative of range
Product Details
TSED Series
Extended temperature range for power supply applications
Electrical connections via PCB snap-in terminals on a unified 10mm pitch
High ripple capability, long life
| Capacitance Tolerance | 20 % |
| Operating Temperature | -40 to +105°C (≤250 V) -25 to +105 °C (>250 V) |
| Leakage current | 3 CV μA |
| Life Expectancy | 3000 hours at 105°C |
Specifications
| Capacitance | 82 µF | |
| Technology | Electrolytic | |
| Voltage | 450 V dc | |
| Mounting Type | Through Hole | |
| Dimensions | 25 (Dia.) x 25mm | |
| Height | 25mm | |
| Diameter | 25mm | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 10mm | |
| Construction | Snap-In | |
| Series | ED SNAP IN | |
| Equivalent Series Resistance | 1.617Ω | |
| Lead Diameter | 0.8mm | |
| Lifetime | 3000h | |
| Tolerance Plus | +20% | |
| Terminal Type | Through Hole | |
| Tolerance | ±20% | |
| Ripple Current | 800mA | |
| Tolerance Minus | -20% |
To view the datasheet please Click Here
