1 x Panasonic Aluminium Electrolytic Capacitor 2200uF 63V dc 22mm UP Series - Panasonic

roll over the image to zoom in

£0.00
£5.99
RS 127-509 (in bag with part number 790-0156)
Earn0
reward points

In stock: 21

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 36K Marked RS 790-0156


    Panasonic

    Panasonic Aluminium Electrolytic Capacitor 2200μF 63V dc 22mm UP Series, Through Hole Electrolytic, ±20%

    • BMUK Part No.127-509
    • BrandPanasonic
    • Mfr Part No.ECOS1JP222BA
    Panasonic

    Product Details

    TSUP Series







    2-Pin 85°C

    Specifications

    Voltage
    63V dc
    Tolerance Plus
    +20%
    Tolerance Minus
    -20%
    Technology
    Electrolytic
    Mounting Type
    Through Hole
    Brand
    Panasonic
    Dimensions
    22 (Dia.) x 30mm
    Capacitance
    2200µF
    Diameter
    22mm
    Maximum Operating Temperature
    +85°C
    Minimum Operating Temperature
    -40°C
    Series
    UP
    Height
    30mm
    Lead Diameter
    0.8mm
    Ripple Current
    2.52A
    Lead Pitch
    10mm
    Lifetime
    3000h
    Tolerance
    ±20%
    Equivalent Series Resistance
    151mΩ
