1 x Panasonic Aluminium Electrolytic Capacitor 100uF 450V dc Through Hole +85°C - Panasonic
roll over the image to zoom in
£0.00
£5.99
RS 790-0531
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 59O
Panasonic
Panasonic Aluminium Electrolytic Capacitor 100μF 450V dc 25mm Through Hole UP type TS Series +85°C
- BMUK Part # : 790-0531
- BrandPanasonic
- Mfr. Part No.ECEC2WP101CJ
- You will get 1 Capacitor
Image representative of range
Product Details
UP Series type TS
Compact size general purpose aluminium electrolytic capacitors featuring snap-in terminals on a unified 10mm pitch
Ideal for PCB applications which require high component densities
Recommended PCB hole size 2mm diameter
Specifications
| Capacitance | 100 µF | |
| Technology | Electrolytic | |
| Voltage | 450 V dc | |
| Mounting Type | Through Hole | |
| Dimensions | 25 (Dia.) x 30mm | |
| Height | 30mm | |
| Diameter | 25mm | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +85°C | |
| Lead Pitch | 10mm | |
| Construction | Snap-In | |
| Series | UP type TS | |
| Ripple Current | 930mA | |
| Terminal Type | Through Hole | |
| Lead Diameter | 2mm | |
| Lifetime | 2000h | |
| Tolerance Plus | +20% | |
| Tolerance | ±20% | |
| Tolerance Minus | -20% |
