1 x ON Semi NDF10N62ZG N-Channel MOSFET Transistor 10A 620V 3-Pin TO-220FP - ON Semiconductor
roll over the image to zoom in
£0.00
£5.99
RS 719-2831
Unit Quantity:
1
Unit Type:
Unit
Location:
TS BRA-2H
ON Semiconductor
NDF10N62ZG N-Channel MOSFET Transistor, 10 A, 620 V, 3-Pin TO-220FP ON Semiconductor
- RS Stock No.719-2831
- BrandON Semiconductor
- Mfr Part No.NDF10N62ZG
-
- You will get ONE mosfet
Product Details
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
10.63mm
Typical Turn-On Delay Time
15 ns
Brand
ON Semiconductor
Typical Turn-Off Delay Time
40 ns
Maximum Continuous Drain Current
10 A
Package Type
TO-220FP
Maximum Power Dissipation
36 W
Mounting Type
Through Hole
Minimum Operating Temperature
-55 °C
Width
4.9mm
Height
16.12mm
Maximum Drain Source Resistance
750 mΩ
Maximum Drain Source Voltage
620 V
Pin Count
3
Dimensions
10.63 x 4.9 x 16.12mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
47 nC @ 10 V
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
1425 pF @ 25 V
Channel Type
N
Maximum Gate Source Voltage
-30 V, +30 V
