1 x Omron Power OFF Delay Single Timer Relay, SPDT, 2 Contacts 100-120V ac - OMRON
roll over the image to zoom in
£0.00
£82.99
RS 106-6246
Unit Quantity:
1
Unit Type:
Unit
Location:
ES-4D
OMRON
Omron Power OFF Delay Single Timer Relay, Screw, 1 → 120 s, SPDT, 2 Contacts, SPDT, 100 → 120 V ac
- BMUK Part Number.106-6246
- BrandOmron
- Mfr Part No.H3DT-HCL
-
- You will get 1 Relay
Product Details
H3DT-H Off Delay Timer
Solid-sate time delay relays with push in plus technology are used for in-panel applications. They are ideal in space saving applications due to their slim design and help reduce work in control panels. The timers reduce power consumption by up to 60% to help reduce heat generation in control panels.
Off Delay
Specifications
Width
90mm
Time Range
1 → 120 s
Number of Contacts
2
Brand
Omron
Contact Configuration
SPDT
Power Supply
External
Minimum Operating Temperature
-20°C
Maximum Operating Temperature
+60°C
Terminal Type
Screw
Time Increment
Seconds
Series
H3DT
Contact Material
Silver Alloy
Maximum Voltage
30 V dc, 250 V ac
Current Maximum
5 A
Supply Voltage
100 → 120 V ac
Mounting Type
DIN Rail
Number of Timer Functions
Single
Mode of Operation
Power OFF Delay
Length
17.5mm
Depth
100mm
Switch Configuration
SPDT
