1 x Ohmite L225J20KE Solder High Power Wire Wound Resistor, 20kΩ ±5% 225W - Ohmite

roll over the image to zoom in

£0.00
£45.99
RS 892-5089
Earn0
reward points

In stock: 25

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 3E + OV


    Ohmite

    Ohmite L225 Series Solder High Power Wire Wound Resistor, 20kΩ ±5% 225W


    BMUK Part # :-892-5089BrandOhmiteMfr. Part No.L225J20KE

               You will get 1 Resistor



    Product Details

    Ohmite 270 Series Fixed Resistors

    Ohmite 270 Series fixed resistors for applications requiring wattage ratings from 12 to 1000 watts. The 270 series resistors are equipped with lug terminals suitable for soldering or sturdy bolt connection. When secure mounting is required, the hollow core of these resistors permit fastening with spring-type brackets, thru bolts or slotted-steel brackets. The 270 series resistors are suitable for rugged applications, and feature an all-welded construction and durable lead free vitreous enamel coating.

    Terminals suitable for soldering or bolt connection
    High wattage applications
    Rugged lead free vitreous enamel coating
    Flame resistant coating
    All-welded construction


    Wirewound-Fixed

    Specifications


    Resistance20 kΩ
    Power Rating225W
    SeriesL225
    Tolerance±5%
    TechnologyWire Wound
    Termination StyleSolder
    Minimum Operating Temperature+25°C
    Maximum Operating Temperature+350°C
    Minimum Temperature Coefficient-260ppm/°C
    Maximum Temperature Coefficient+260ppm/°C
    Temperature Coefficient±260ppm/°C
    Overall Diameter28.6mm
    Dimensions28.6 (Dia.) x 266.7mm
    Overall Length266.7mm




    To view the datasheet please Click Here
