1 x OEP1200D 600Ω 1:1 Ratio Telecom Line Isolating Transformer BABT Through Hole - OEP
roll over the image to zoom in
£0.00
£7.99
RS 210-6223
Unit Quantity:
1
Unit Type:
Unit
OEP
OEP 1:1 Through Hole Telecom Transformer, 4.15h, 65Ω
- BMUK Part # :-210-6223
- BrandOEP
- Mfr. Part No.OEP1200D
- You will get 1 Transformer
Product Details
OEP, Line Isolating Transformers
From OEP, this selection of compact encapsulated PCB and surface mount line isolating transformers are for use in data transmission applications. They are approved and certified for use in telecommunications circuits required to meet BS6305 (Speech and Non-Speech Class A) providing the line hold current is diverted from the windings by a choke or other electronic means. Constructed from resin encapsulated in a glass filled nylon box, these line isolating transformers are flame retardant to UL94-V0 requirements.
| Technical specification | |
| Primary Impedance | 600Ω |
| Secondary Impedance | 600Ω |
Approvals
BABT
Standards
BS415; EN60950; EN41003
600 Ohm Line Isolating, Pulse Matching and High Frequency Transformers
Specifications
| Primary Inductance | 4.15H | |
| Primary DC Resistance | 65Ω | |
| Secondary DC Resistance | 65Ω | |
| Insertion Loss | 1.3dB | |
| Turns Ratio | 1:1 | |
| Mounting Type | Through Hole | |
| Leakage Inductance | 20mH | |
| Dimensions | 18 x 18 x 12.5mm | |
| Depth | 12.5mm | |
| Length | 18mm | |
| Width | 18mm | |
| Maximum Operating Frequency | 4kHz | |
| Minimum Operating Frequency | 300Hz | |
| Minimum Temperature | 0°C | |
| Maximum Temperature | +70°C |
For a Specification PDF Please CLICK HERE
