1 x NXP HEF4049BP Hex CMOS Inverter, 3-15 V, 16-Pin PDIP - NXP
roll over the image to zoom in
£0.00
£5.49
RS 306-667 - 3D Print 100 Green
Unit Quantity:
1
Unit Type:
Unit
Location:
3D Print Right Green Draws 100
NXP
Phillips/NXP HEF4049BP, Hex, CMOS Inverter, 3 → 15 V, 16-Pin PDIP
- BMUK Part # :-306-667
- BrandNXP
- Mfr Part No.HEF4049BP,652
-
- You will get ONE IC, Branded NXP
Product Details
4000 Series Inverters & Buffers, NXP Semiconductors
4000 CMOS Logic Family, Nexperia
Specifications
Maximum High Level Output Current
-2.4mA
Maximum Operating Temperature
+85 °C
Number of Elements per Chip
6
Length
19.5mm
Schmitt Trigger Input
No
Minimum Operating Supply Voltage
3 V
Maximum Propagation Delay Time @ Maximum CL
100 ns @ 5 V, 40 ns @ 15 V, 50 ns @ 10 V
Brand
NXP
Propagation Delay Test Condition
50pF
Package Type
PDIP
Mounting Type
Through Hole
Minimum Operating Temperature
-40 °C
Width
6.48mm
Logic Family
4000
Height
3.2mm
Logic Function
Inverting Buffer
Output Type
CMOS
Maximum Operating Supply Voltage
15 V
Pin Count
16
Dimensions
19.5 x 6.48 x 3.2mm
Maximum Low Level Output Current
24mA
