1 x NXP 8bit 80C51 Microcontroller P87C51SBPN,112, Through Hole, 16MHz, 4kB - NXP
roll over the image to zoom in
£0.00
£32.99
RS 302-1735
Unit Quantity:
1
Unit Type:
Unit
Location:
TS BRA-7L
NXP
NXP P87C51SBPN,112, 8bit 80C51 Microcontroller, 16MHz, 4 kB EPROM, 40-Pin PDIP
- BMUK Part # :-302-1735
- BrandNXP
- Mfr. Part No.P87C51SBPN,112
- You will get 1 Microcontroller
Product Details
80C51 Family Microcontrollers, NXP
80C51 Microcontrollers, NXP
Specifications
| Family Name | P87C | |
| Package Type | PDIP | |
| Mounting Type | Through Hole | |
| Pin Count | 40 | |
| Device Core | 80C51 | |
| Data Bus Width | 8bit | |
| Program Memory Size | 4 kB | |
| Maximum Frequency | 16MHz | |
| RAM Size | 128 B | |
| Number of PWM Units | 1 | |
| Typical Operating Supply Voltage | 2.7 → 5.5 V | |
| Number of Timers | 3 | |
| Width | 14.1mm | |
| Program Memory Type | EPROM | |
| PWM Resolution | 16bit | |
| Instruction Set Architecture | CISC | |
| Minimum Operating Temperature | 0 °C | |
| PWM Channels | 3 | |
| Timer Resolution | 16bit | |
| Timers | 3 x 16 bit | |
| Dimensions | 52.5 x 14.1 x 4mm | |
| Length | 52.5mm | |
| Pulse Width Modulation | 3 x 16 bit | |
| Number of UART Channels | 1 | |
| Maximum Operating Temperature | +70 °C | |
| Height | 4mm |
To view the datasheet please Click Here
