1 x NXP 8-Input NAND Logic Gate HEF4068BP, Through Hole, 5-15V, 14-Pin - NXP
roll over the image to zoom in
£0.00
£7.49
RS 791-8832
Unit Quantity:
1
Unit Type:
Unit
Location:
TS BRA-10J ALSO 12H
NXP
NXP HEF4068BP, 8-Input NAND Logic Gate, 5 → 15 V, 14-Pin PDIP
- BMUK Part # :-791-8832
- BrandNXP
- Mfr. Part No.HEF4068BP
- You will get 1 IC
Product Details
4000 Series Logic Gates, NXP Semiconductors
4000 CMOS Logic Family, NXP Semiconductors
CMOS Family devices
Wide operating voltage range: 3 to 18V
Specifications
| Logic Function | NAND | |
| Mounting Type | Through Hole | |
| Number of Elements | 1 | |
| Number of Inputs per Gate | 8 | |
| Schmitt Trigger Input | No | |
| Package Type | PDIP | |
| Pin Count | 14 | |
| Logic Family | 4000 | |
| Input Type | CMOS | |
| Maximum Operating Supply Voltage | 15 V | |
| Maximum Propagation Delay Time @ Maximum CL | 60 ns @ 15 V | |
| Minimum Operating Supply Voltage | 5 V | |
| Width | 6.48mm | |
| Height | 3.2mm | |
| Maximum Operating Temperature | +85 °C | |
| Output Type | Current, Voltage | |
| Propagation Delay Test Condition | 50pF | |
| Length | 19.5mm | |
| Dimensions | 19.5 x 6.48 x 3.2mm | |
| Minimum Operating Temperature | -40 °C |
To view the datasheet please Click Here
Nichicon Aluminium Polymer Capacitor 330μF 2.5 V dc 6.3mm Through Hole LS Series Lifetime 5000h
Product Details
LS Series Solid Electrolytic Radial
Solid Radial 105°C
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Capacitance | 330 µF | |
| Technology | Polymer | |
| Voltage | 2.5 V dc | |
| Dimensions | 6.3 (Dia.) x 9mm | |
| Height | 9mm | |
| Diameter | 6.3mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 2.5mm | |
| Construction | Radial | |
| Series | LS | |
| Terminal Type | Through Hole | |
| Lifetime | 5000h | |
| Leakage Current | 500 μA | |
| Board Level Components | Y | |
| Lead Diameter | 0.6mm | |
| Ripple Current | 4.8A | |
| Tolerance Minus | -20% | |
| Tolerance | ±20% | |
| Tolerance Plus | +20% | |
| Equivalent Series Resistance | 8mΩ |
TDK 4.7μF Multilayer Ceramic Capacitor MLCC 25 V dc ±10% X7R Dielectric 1210 Surface Mount Max. Op. Temp. +125°C
Product Details
TDK Type 1210 Series C3225
MLCC C Series is a monolithic structure that ensures superior mechanical strength and reliability.
High capacitance has been achieved through precision technologies that enable the use of multiple thinner ceramic dielectric layers.
Features and Benefits
Low ESL and excellent frequency characteristics allow for a circuit design that closely conforms to theoretical valuesLow self-heating and high ripple resistance due to low ESR
Applications:
• General Electronic Equipment• Mobile Communication Equipment
• Power Supply Circuit
• Office Automation Equipment
• TV, LED displays
• Servers, PCs, Notebooks, Tablets"
1210 Range
Add product to Compare
Specifications
Not what you’re looking for? Select the attributes you require, then click the button below
| Capacitance | 4.7 µF | |
| Voltage | 25 V dc | |
| Package/Case | 1210 | |
| Dielectric | X7R | |
| Tolerance | ±10% | |
| Dimensions | 3.2 x 2.5 x 2mm | |
| Length | 3.2mm | |
| Depth | 2.5mm | |
| Height | 2mm | |
| Series | C | |
| Tolerance Minus | -10% | |
| Tolerance Plus | +10% | |
| Temperature Coefficient | ±15% | |
| Terminal Type | Surface Mount | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +125°C |
