1 x Murata Power Solutions DC-DC Converter NDXD1212C, Vin 9-18V dc, 1kV dc - Murata Power Solutions
roll over the image to zoom in
£0.00
£31.99
RS 725-7180
Unit Quantity:
1
Unit Type:
Unit
Location:
BRA 12P
Murata Power Solutions
Murata Power Solutions Through Hole Isolated DC-DC Converter, Vin 9 → 18 V dc, I/O isolation 1kV dc
- BMUK Part # :-725-7180
- BrandMurata Power Solutions
- Mfr. Part No.NDXD1212C
-
- You will get 1 DC-DC Converter
Product Details
Murata 7.5W DIP Single/Dual Output Regulated Isolated DC-DC Converter - NDX Series
7.5W regulated single/dual output DC to DC converters with an industry-standard 5 pinout. These 7.5W DC to DC converters have an unbalanced loading capability with an optional input control pin which will shut down the NDX from TTL levels.
Wide 2:1 voltage input range
Optional input control pin
Continuous short circuit protection with current foldback
Efficiency from 67%
Power density 0.9W / cm3
Optional remote On/Off
Low noise
No electrolytic capacitors
UL 94V-0 package materials
Note
MTBF to MIL-HDBK-217F (25°)
Murata Power Solutions - DIP
Specifications
| Output Voltage | ±12V dc | |
| Input Voltage Range | 9 → 18 V dc | |
| Input Voltage Nominal | 12 V dc | |
| Isolation Voltage | 1kV dc | |
| Output Current | ±0.312A | |
| Mounting Type | Through Hole | |
| Number of Outputs | 2 | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Series | NDX | |
| Board Level Components | Y | |
| Depth | 10mm | |
| Length | 32mm |
