1 x Microchip PIC18F252-I/SP 8bit PIC Microcontroller, 40MHz 32kB Flash, 28-Pin - Microchip
roll over the image to zoom in
£0.00
£8.99
RS 467-2047
Unit Quantity:
1
Unit Type:
Unit
Location:
TS BRA-10C
Microchip
Microchip PIC18F252-I/SP, 8bit PIC Microcontroller, 40MHz, 32 kB Flash, 28-Pin SPDIP
- BMUK Part # :- 467-2047
- BrandMicrochip
- Mfr. Part No.PIC18F252-I/SP
-
- You will get 1 Microcontroller
Product Details
PIC18F242/252/442/452 8-Bit Flash Microcontrollers
Specifications
| Family Name | PIC18F | |
| Package Type | SPDIP | |
| Mounting Type | Through Hole | |
| Pin Count | 28 | |
| Device Core | PIC | |
| Data Bus Width | 8bit | |
| Program Memory Size | 32 kB | |
| Maximum Frequency | 40MHz | |
| RAM Size | 1536 B | |
| Number of PWM Units | 2 | |
| ADC Channels | 5 | |
| Number of SPI Channels | 1 | |
| Typical Operating Supply Voltage | 4.2 → 5.5 V | |
| Dimensions | 35.18 x 7.49 x 3.43mm | |
| Length | 35.18mm | |
| Pulse Width Modulation | 2(10 bit) (CCP) | |
| Maximum Operating Temperature | +85 °C | |
| Height | 3.43mm | |
| Number of I2C Channels | 1 | |
| Minimum Operating Temperature | -40 °C | |
| Instruction Set Architecture | RISC | |
| PWM Resolution | 10bit | |
| Program Memory Type | Flash | |
| Width | 7.49mm | |
| ADCs | 5 x 10 bit | |
| Number of USART Channels | 1 | |
| Number of ADC Units | 1 | |
| Number of Timers | 4 | |
| ADC Resolution | 10bit | |
| Timer Resolution | 8 bit, 16 bit | |
| Timers | 2 x 16 bit, 2 x 8 bit |
