1 x Microchip MCP1825S-3002E/DB LDO Voltage Regulator 500mA 3V, ±0.5% SOT-223 - Microchip

roll over the image to zoom in

£0.00
£5.49
RS 669-5089
Earn0
reward points

In stock: 20

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS BRA-2H


    Microchip

    Microchip MCP1825S-3002E/DB, LDO Voltage Regulator, 500mA, 3 V, ±0.5% 4-Pin, SOT-223

    • BMUK Stock No.669-5089
    • BrandMicrochip
    • Mfr Part No.MCP1825S-3002E/DB
    •
    •  Microchip
    •
    • You will get ONE voltage regulator
    Microchip MCP1825S-3002E/DB, LDO Voltage Regulator, 500mA, 3 V, ±0.5% 4-Pin, SOT-223
    Product Details

    MCP1825 Low Dropout Voltage Regulator

    LDO (Low Dropout) Linear Voltage Regulators, Microchip

    Specifications
    Maximum Operating Temperature
    +125 °C
    Accuracy
    ±0.5%
    Line Regulation
    0.05 %/V
    Length
    6.5mm
    Number of Outputs
    1
    Brand
    Microchip
    Package Type
    SOT-223
    Minimum Input Voltage
    2.1 V
    Load Regulation
    0.5 %
    Mounting Type
    Surface Mount
    Quiescent Current
    0.12mA
    Minimum Operating Temperature
    -40 °C
    Width
    3.5mm
    Height
    1.6mm
    Output Type
    Fixed
    Pin Count
    4
    Dimensions
    6.5 x 3.5 x 1.6mm
    Maximum Input Voltage
    6 V
    Output Voltage
    3 V
    Maximum Output Current
    500mA
