1 x Micrel LDO Voltage Regulator, 1A Adjustable, 1.24-16 V, ±1% 8-Pin, SOIC - Micrel

roll over the image to zoom in

£0.00
£5.49
RS 453-479
Earn0
reward points

In stock: 20

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS BRA-2H


    Micrel

    Micrel LDO Voltage Regulator, 1A Adjustable, 1.24 → 16 V, ±1% 8-Pin, SOIC

    • RS Stock No.453-479
    • BrandMicrel
    • Mfr Part No.MIC39102YM
    •
    •  Micrel
    •
    • You will get ONE voltage regulator
    Micrel LDO Voltage Regulator, 1A Adjustable, 1.24 → 16 V, ±1% 8-Pin, SOIC
    Product Details

    MIC39102 1A Low Dropout Voltage Regulator

    LDO (Low Dropout) Linear Voltage Regulators, Microchip

    Specifications
    Maximum Operating Temperature
    +125 °C
    Accuracy
    ±1%
    Line Regulation
    0.5 %
    Length
    4.93mm
    Number of Outputs
    1
    Brand
    Micrel
    Polarity
    Positive
    Package Type
    SOIC
    Minimum Input Voltage
    2.25 V
    Load Regulation
    1 %
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -40 °C
    Width
    3.94mm
    Height
    1.48mm
    Output Type
    Adjustable
    Pin Count
    8
    Dimensions
    4.93 x 3.94 x 1.48mm
    Maximum Input Voltage
    16 V
    Output Voltage
    1.24 → 16 V
    Maximum Output Current
    1A
    Reference Voltage
    1.252V
