IXYS, R0830LC14D-U9900, Thyristor, 1400V 830A, 300mA 2-Pin, R0830
- BMUK Part # :-768-9029
- BrandIXYS
- Mfr. Part No.R0830LC14D-U9900
- You will get 1 Thyristor
Product Details
Distributed Gate Capsule Thyristor, IXYS
Supplied with
Cathode and gate pins.
Thyristors - IXYS
A Thyristor is a solid-state semiconductor device with four layers of alternating N and P-type material. They act as bistable switches, conducting when their gate receives a current trigger, and continue to conduct while they are forward biased. Thyristors are synonymous to Silicon-Controlled Rectifier (SCR).
Encapsulated modules with electrically isolated base plate. Suitable for applications such as battery chargers, welders and plating equipment, regulated power supplies and temperature and speed control circuits.
Specifications
| Rated Average On-State Current | 830A | |
| Thyristor Type | SCR | |
| Package Type | R0830 | |
| Repetitive Peak Reverse Voltage | 1400V | |
| Surge Current Rating | 8500A | |
| Mounting Type | Stud | |
| Maximum Gate Trigger Current | 300mA | |
| Maximum Gate Trigger Voltage | 3V | |
| Maximum Holding Current | 1000mA | |
| Pin Count | 2 | |
| Height | 27mm | |
| Dimensions | 58.5 (Dia.) x 27mm | |
| Peak On-State Voltage | 2.4V | |
| Maximum Operating Temperature | +125 °C | |
| Board Level Components | Y | |
| Diameter | 58.5mm | |
| Minimum Operating Temperature | -40 °C | |
| Repetitive Peak Forward Blocking Voltage | 1400V | |
| Repetitive Peak Off-State Current | 70mA |
To view the datasheet please Click Here
