1 x Ioxus 350F Electric Double Layer Capacitor RSC2R7357S4, -5-+10%, 2.7V - Ioxus

roll over the image to zoom in


£0.00
£15.99

RS 769-0228
Earn0
reward points

In stock: 2

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 49N


    Ioxus

    Ioxus 350F Electric Double Layer Capacitor -5 → +10% Tolerance Snap-In Hybrid, Supercap RSC Series 2.7 V


    • BMUK Part # :-769-0228
    • BrandIoxus
    • Mfr. Part No.RSC2R7357S4
    •
    •
    • You will get 1 Capacitor







    Product Details

    RSC series Snapin Super Capacitor Multipin

    Board mountable High power, high rate cycling, Long life (>500000 cycles) cells
    Multipin terminals for more secure connection
    Applications include Wind turbine control, Starting systems, Automotive subsystems, Emergency lighting, Backup/UPS and Renewable energy systems


    Aluminium (EDLC) Super Capacitors


    Specifications


    Capacitance350 F

    Voltage2.7 V

    Mounting TypeThrough Hole

    Minimum Operating Temperature-40°C

    Maximum Operating Temperature+65°C

    Diameter35mm

    Dimensions35 x 62mm

    Lead Pitch20mm

    Leakage Current1 mA

    Equivalent Series Resistance2.4 (ac) mΩ, 2.7 (dc) mΩ

    Lifetime1000h

    SeriesSnap-In Hybrid, Supercap RSC

    Tolerance-5 → +10%

    Terminal TypeThrough Hole

    Lead Diameter2 mm, 3 mm

    Tolerance Minus-5%

    Capacitor FamilySupercapacitor

    Depth62mm

    Tolerance Plus+10%




    For a Specification PDF Please CLICK HERE







    Thank you for looking, if you have any questions please ask or call us.
    Please see our other items for a wide range of Electronic components.
