1 x Intersil ISL26132AVZ 24 bit Serial ADC, 2 CH Differential Input PGA, 5V 3V3 - Intersil
roll over the image to zoom in
£0.00
£7.99
RS 767-3591
Unit Quantity:
1
Unit Type:
Unit
Location:
BRA 14B
Intersil
Intersil ISL26132AVZ, 24 bit Serial ADC, 2CH Differential Input, 24-Pin TSSOP
BMUK Part # :-767-3591BrandIntersilMfr. Part No.ISL26132AVZ You will get 1 ADC
Product Details
Analogue to Digital Converters 24 Bit, Intersil
Analogue to Digital Converters - Intersil
Specifications
Resolution24 bit
Number of ADCs1
Digital Interface TypeSerial
Mounting TypeSurface Mount
Sampling Rate80sps
ArchitectureDelta Sigma
Typical Single Supply Voltage3.3 V, 5 V
Package TypeTSSOP
Pin Count24
Input Signal TypeDifferential
Input TypeVoltage
Power Supply TypeSingle
Integral Nonlinearity Error±0.001%FSR
Maximum Operating Temperature+105 °C
Length7.8mm
Width4.4mm
Dimensions7.8 x 4.4 x 1.1mm
Minimum Operating Temperature-40 °C
Height1.1mm
To view the datasheet please Click Here
Please visit our shop to see all our other items we have in stock,
Please call us if you have any questions,
Many thanks!
