1 x Infineon IRG4PC40UPBF IGBT, 40A 600V, 3-Pin TO-247AC - Infineon
roll over the image to zoom in
£0.00
£5.99
RS 166-1046
Unit Quantity:
1
Unit Type:
Unit
Model:
IRG4PC40UPBF
Location:
TS BRA-2E
Infineon
Infineon IRG4PC40UPBF IGBT, 40 A 600 V, 3-Pin TO-247AC
- BMUK Stock No.166-1046
- BrandInfineon
- Mfr Part No.IRG4PC40UPBF
- You will get ONE IGBT
-
Product Details
Single IGBT up to 20A, Infineon
Optimised IGBTs designed for medium frequency applications with fast response which provide the user with the highest efficiency available. These devices utilise FRED diodes optimised to provide the best performance with IGBTs
IGBT Transistors, International Rectifier
International Rectifier offers an extensive IGBT (Insulated-Gate Bipolar Transistor) portfolio ranging from 300V to 1200V based on various technologies that minimize switching and conduction losses to increase efficiency, reduce thermal problems and improve power density. The company also offers a broad range of IGBT dies designed specifically for medium- to high-power modules. For modules that demand the highest reliability, solderable front metal (SFM) dies can be employed to eliminate bond wires and allow double-sided cooling for improved thermal performance, reliability and efficiency.
Specifications
Maximum Operating Temperature
+150 °C
Length
15.9mm
Transistor Configuration
Single
Brand
Infineon
Maximum Collector Emitter Voltage
600 V
Maximum Continuous Collector Current
40 A
Package Type
TO-247AC
Mounting Type
Through Hole
Minimum Operating Temperature
-55 °C
Width
5.3mm
Height
20.3mm
Pin Count
3
Dimensions
15.9 x 5.3 x 20.3mm
Maximum Gate Emitter Voltage
±20V
Channel Type
N
