1 x Infineon IPW65R190CFDAFKSA1 N-Channel MOSFET 17.5A 650V CoolMOS CFD TO-247 - Infineon
roll over the image to zoom in
£0.00
£5.95
RS 165-5262
Unit Quantity:
1
Unit Type:
Unit
Model:
IPW65R190CFDAFKSA1
Location:
TS BRA-12A
Infineon
IPW65R190CFDAFKSA1 N-Channel MOSFET, 17.5 A, 650 V CoolMOS CFD, 3-Pin TO-247 Infineon
- BMUK Stock No.165-5262
- Brand
- Mfr Part No.IPW65R190CFDAFKSA1
Product Details
Infineon CoolMOS™ CFD Power MOSFET
MOSFET Transistors, Infineon
Specifications
Maximum Operating Temperature
+150 °C
Maximum Continuous Drain Current
17.5 A
Package Type
TO-247
Maximum Power Dissipation
151 W
Mounting Type
Through Hole
Width
5.16mm
Height
21.1mm
Dimensions
16.03 x 5.16 x 21.1mm
Transistor Material
Si
Number of Elements per Chip
1
Length
16.03mm
Transistor Configuration
Single
Typical Turn-On Delay Time
12 ns
Brand
Infineon
Typical Turn-Off Delay Time
53.2 ns
Series
CoolMOS CFD
Minimum Operating Temperature
-40 °C
Maximum Gate Threshold Voltage
4.5V
Minimum Gate Threshold Voltage
3.5V
Maximum Drain Source Resistance
190 mΩ
Maximum Drain Source Voltage
650 V
Pin Count
3
Category
Power MOSFET
Typical Gate Charge @ Vgs
68 nC @ 10 V
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
1850 pF @ 100 V
Channel Type
N
Maximum Gate Source Voltage
-30 V, +30 V
