1 x Honeywell 2455RP 9100-444 F70C, NO 10A Thermostat Solder Tag, 0°C +186°C - Honeywell
roll over the image to zoom in
£0.00
£8.99
RS 229-5963
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 9O
Honeywell
Honeywell NO 10 A Thermostat, Solder Tag Termination, 0°C +186°C
- BMUK Part # :-229-5963
- BrandHoneywell
- Mfr. Part No.2455RP 9100-444 F70C
-
- You will get 1 Thermostat
Product Details
Basic Bi-MetallicThermostat
PPS Ryton body with steel end cap
Electrical terminals parallel to the mounting face and a floating steel bracket to ease mounting and increase temperature tolerance
N/C types open on temperature rise, N/O types close on temperature rise
1/4in. tab termination
Contacts are rated to 250Vac 10A with a maximum contact resistance of 50mΩ
Dielectric strength of 2000Vac
Note
The contacts are NOT silver plated and are unsuitable for use with low current dc applications
Thermal Switches
Specifications
| Minimum Temperature | 0°C | |
| Maximum Temperature | +186°C | |
| Opening Temperature | +55°C | |
| Closing Temperature | +70°C | |
| Switch Configuration | NO | |
| Contact Rating | 10 A | |
| Contact Voltage Rating | 250 V ac | |
| Terminal Type | Solder Tag |
For a Specification PDF Please CLICK HERE
