1 x Fuji Electric 2MBi200VH-120-50, M276 Series IGBT Module, 240A max, 1200V - Fuji Electric

roll over the image to zoom in

£0.00
£141.99
RS 747-1080
Earn0
reward points

In stock: 0

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS 30O


    Fuji Electric

    Fuji Electric 2MBi200VH-120-50, M276 Series IGBT Module, 240 A max, 1200 V, Panel Mount


    • BMUK Part # :-747-1080
    • BrandFuji Electric
    • Mfr. Part No.2MBi200VH-120-50
    •
    •
    • You will get 1 IGBT Module













    Product Details

    IGBT Modules 2-Pack, Fuji Electric

    V-Series, 6th Generation Field-Stop
    U/U4 Series, 5th Generation Field-Stop
    S-Series, 4th Generation NPT


    IGBT Discretes & Modules, Fuji Electric

    The Insulated Gate Bipolar Transistor or IGBT is a three-terminal power semiconductor device, noted for high efficiency and fast switching. The IGBT combines the simple gate-drive characteristics of the MOSFETs with the high-current and low–saturation-voltage capability of bipolar transistors by combining an isolated gate FET for the control input, and a bipolar power transistor as a switch, in a single device.

    Specifications


    		Transistor ConfigurationSeries

    		ConfigurationSeries

    		Maximum Continuous Collector Current240 A

    		Maximum Collector Emitter Voltage1200 V

    		Maximum Gate Emitter Voltage±20V

    		Channel TypeN

    		Mounting TypePanel Mount

    		Package TypeM276

    		Pin Count7

    		Maximum Power Dissipation1110 W

    		Dimensions108 x 62 x 30.5mm

    		Height30.5mm

    		Length108mm

    		Maximum Operating Temperature+150 °C

    		Width62mm

    For a Specification PDF Please CLICK HERE
