TE Connectivity FSN-22A-15 Flat Ribbon Cable
15 Way 50.8mm Long FLEXSTRIP PCB Connector

• FLEXSTRIP Series



  • BMUK Part # :-299-1071
  • BrandTE Connectivity
  • Mfr. Part No.FSN-22A-15
  •
  • You will get ONE 15 Way Ribbon Cable


















  Product Details

  Jumper Leads

  FLEXSTRIP® jumpers are multi-conductor board- to -board interconnect devices. They provide a convenient, reliable alternative to conventional point to point wiring for high density, high vibration PCB interconnections. Two types are available: those made from Nomex material are suitable for standard applications where changes of direct resistance due to humidity are not critical; those made from PTFE are ideal for high electrical and mechanical performance applications.

  The product can be repeatably flexed without failure, reliable vibration- and break proof connection
  No long preparation times for connecting PCBs, no cutting into sections, no preliminary work
  Can be installed by most commonly used soldering techniques
  High processsing speed,e.g soldering all the wiring points in the soldering bath simultaneously

  Insulation	Nomex: UL Style 5295
  	PTFE: UL Style 2928
  Equivalent Conductor Size	0.203mm²
  Conductor Material	Cu/acc. QQ-W-343
  Insulation Resistance (gnd,sig,gnd)	>1 GΩ
  Operating Temperature	125°C
  Soldering Temperature	250°C/4s
  Current Rating	3A
  Voltage Rating	300V
  Dielectric Strength	1500Vac







  Dimensions (mm)
  Pitch	A	2.54
  Length	B	25.4, 50.8, 76.2
  Margin max	C	0.8
  Margin min	C	0.25
  Max Thickness	D	0.75
  Mid Pin Thickness max	F	0.37
  Mid Pin Thickness min	F	0.33
  Pin Diameter max	E	0.53
  Pin Diameter min	E	0.51
  Min Bending Diameter	-	3.18



  Note

  These jumpers are suitable for use with the FLEXSTRIP® sockets range

  Flexstrip® is a registered trade name of tyco Electronics AMP corporation





  2.54mm TE Connectivity Flexstrip Range






  Specifications







  	Pitch	2.54mm
  	American Wire Gauge	24
  	Voltage Rating	300 V
  	Hi-Flex	Yes
  	Minimum Operating Temperature	-40°C
  	Maximum Operating Temperature	+125°C
  	Characteristic Impedance	117 Ω
  	Capacitance	11.2 pF/ft
  	Series	FLEXSTRIP
  	High Density	Yes
