1 x Exar ST16C2552CJ44TR-F Dual Universal Asynchronous Receiver & Transmitter - EXAR
roll over the image to zoom in
£0.00
£12.99
RS 686-5894
Unit Quantity:
1
Unit Type:
Unit
Location:
TS BRA-4i
EXAR
EXAR ST16C2552CJ44TR-F Dual Universal Asynchronous Receiver & Transmitter RS232, RS485 4Mbit/s, 2.97 → 5.5 V
- BMUK Part # :-686-5894
- BrandEXAR
- Mfr. Part No.ST16C2552CJ44-F
-
- You will get 1 IC
Product Details
Universal Asynchronous Receiver/Transmitter (UART), EXAR
Exar offers a variety of UARTs (Universal Asynchronous Receiver Transmitter) with a broad range of first in, first out (FIFO) depths while supporting popular central processing unit (CPU) bus interfaces such as 8-bit VLIO.
A Universal Asynchronous Receiver/Transmitter, abbreviated (UART) and universal synchronous/asynchronous receiver/transmitter (USART) are commonly used in conjunction with communication standards such as EIA, RS-232, RS-422 or RS-485. It takes bytes of data and transmits or receives the individual bits in a sequential fashion. Modem (Modulator-Demodulator) that modulates an analogue carrier signal to encode digital information and demodulates the signal to decode the transmitted information including the UART function for transmission over telephone lines.
Specifications
| Number of Channels per Chip | 2 | |
| Standard Supported | RS232, RS485 | |
| Transmit FIFO | 16B | |
| Receive FIFO | 16B | |
| Maximum Data Rate | 4Mbit/s | |
| Transmitter and Receiver FIFO Counter | Yes | |
| Mounting Type | Surface Mount | |
| Package Type | PLCC | |
| Pin Count | 44 | |
| Typical Operating Supply Voltage | 2.97 → 5.5 V | |
| Dimensions | 16.66 x 16.66 x 3.68mm | |
| Length | 16.66mm | |
| Width | 16.66mm | |
| Height | 3.68mm | |
| Maximum Operating Temperature | +70 °C | |
| Minimum Operating Temperature | 0 °C |
