1 x EVOX RIFA / KEMET 2700uF 420V DC ±20% PEH200OO427AMB2 Electrolytic Capacitor - EVOX RIFA
roll over the image to zoom in
£0.00
£87.95
RS 870-4693
Unit Quantity:
1
Unit Type:
Unit
Capacitor Construction:
Aluminium Electrolytic (Polarised)
Location:
TSB-9B
EVOX RIFA
EVOX RIFA / KEMET 2700μF Electrolytic Capacitor 420V dc, Screw Mount - PEH200OO427AMB2
- BMUK Stock No.870-4693
- BrandEVOX RIFA / KEMET
- Mfr Part No.PEH200OO427AMB2
Product Details
The PEH200 series of aluminium electrolytic converters from KEMET offer long life with low ESR and ESL in a compact size. These electrolytic capacitors feature a polarised, welded design with extended cathode construction, heavy duty screw terminals, plastic insulation and a safety vent. The sealing system allows for a low gas-diffusion rate of electrolyte and electrolyte leakage-free operation.
Features
Industrial grade
Long life, high performance electrolytic capacitors
High CV value with low equivalent series resistance (ESR), and low equivalent series inductance (ESL)
Applications
Ground power units,
Uninterruptible power supplies Welding equipment and drives
Note
Supplied without any nuts, bolts or screws!
Standards
IEC 384-4 long life grade 40/85/56, DIN
AEC-Q200 qualified
Clamp-fixing +85°C
Ideal for computer power supply applications or other applications that require long operational life
Specifications
Length
105mm
Voltage
420V dc
Technology
Electrolytic
Mounting Type
Screw Mount
Brand
KEMET
Dimensions
65 x 105mm
Capacitance
2700µF
Diameter
65mm
Maximum Operating Temperature
+85°C
Minimum Operating Temperature
-40°C
Series
PEH200
Height
105mm
Ripple Current
12.4 (A @100 Hz 85°C), 40.1 (A @10 kHz 40°C), 57.3 (A @10 kHz 50°C)
Lead Pitch
28.5mm
Polarised
Polar
Leakage Current
7.402 μA
Lifetime
15000 h @ +85 °C/420V dc/Ir
Tolerance
±20%
Equivalent Series Resistance
10 mΩ @ 100 kHz, 24 mΩ @ 100 Hz
