1 x Epcos 60uF Polypropylene Capacitor 800V dc ±10%, Through Hole B32778 Series - Epcos
roll over the image to zoom in
£0.00
£31.99
RS 669-0056
Unit Quantity:
1
Unit Type:
Unit
Location:
TS-LB 6M
Epcos
EPCOS 60μF Polypropylene Capacitor PP 800 V dc ±10% Tolerance Through Hole B32778 Series
- BMUK Part # :-669-0056
- BrandEPCOS
- Mfr. Part No.B32778G8606K
-
- You will get 1 Capacitor
Product Details
MKP DC Link B3277x Series
Typical applications are frequency convertors, industrial power supplies, inverters
Polypropylene (MKP) dielectric, plastic case with Epoxy resin seal (UL 94V-0)
Compact high CV product
Excellent self-healing properties
G types have 4 pins to aid with mounting
Specifications
| Capacitance | 60 µF | |
| Voltage | 800 V dc | |
| Mounting Type | Through Hole | |
| Tolerance | ±10% | |
| Series | B32778 | |
| Application | Frequency Converter, Power Supply, Solar Inverter | |
| Lead Pitch | 52.5mm | |
| Length | 57.5mm | |
| Depth | 35mm | |
| Height | 50mm | |
| Dimensions | 57.5 x 35 x 50mm | |
| Dielectric | PLYP | |
| Equivalent Series Resistance | 3mΩ | |
| Tolerance Minus | -10% | |
| Lead Diameter | 1.2mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +105°C | |
| Terminal Type | Through Hole | |
| Tolerance Plus | +10% |
