1 x Epcos 5 uH Ferrite VHF Inductor B82111B0000C021 Max SRF:175MHz, 10A Idc, 5mΩ - Epcos
roll over the image to zoom in
£0.00
£5.49
RS 213-1819
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 41A
Epcos
Epcos 5 μH Ferrite VHF Inductor, Max SRF:175MHz, 10A Idc, 5mΩ Rdc B82111B
- BMUK Part # :-213-1819
- BrandEPCOS
- Mfr. Part No.B82111B0000C021
- You will get 1 Inductor
Product Details
Epcos B82111B VHF Axial Choke
Ferrite cylinder core with single layer, enamel copper wire, winding in polyester insulating sleeve
Offers high resonance frequency
Suitable for RF blocking and filtering, interference suppression in small size equipment, decoupling and telecoms and entertainment electronics
VDE 0565-2 (not B82500)
Epcos Leaded Inductors (Chokes)
Specifications
| Inductance | 5 μH | |
| Maximum DC Current | 10A | |
| Mounting Type | Axial | |
| Maximum DC Resistance | 5mΩ | |
| Diameter | 9.5mm | |
| Length | 34mm | |
| Dimensions | 9.5 (Dia.) x 34mm | |
| Core Material | Ferrite | |
| Maximum Self Resonant Frequency | 175MHz | |
| Series | B82111B |
To view the datasheet please Click Here
