1 x Displaytech 32128A-GC-BW-3 Graphic 128x32 LCD Display Neg Blk/White ST7565V - Displaytech

roll over the image to zoom in

£0.00
£14.99
RS 627-1674
Earn0
reward points

In stock: 75

Sorry! We're out of stock

Add To Your Wishlist


    Displaytech

    Displaytech 32128A-GC-BW-3 Graphic 128x32 LCD Display using the ST7565V Driver IC



    You will get ONE LCD Display



    • BrandDisplaytech
    • Mfr. Part No.32128A-GC-BW-3
    • Serial and Parallel Interfaces
    Displaytech
    Graphic 128x32 COG FSTN neg blk/white
    Product Details

    128 x 32 Pixel, Supertwist Back-lit

    Range of 128 x 32 pixel displays

    1 / 32 duty cycle
    Dot Size: 0.36 x 0.41mm
    View Area: 54.8 x 19.1mm
    Module Size: 65.6 x 29.2mm
    White or RGB LED backlight options

    The 32128A is our smallest standard monochrome graphic LCD module.  This LCD is ideal for remote controls and hand held products, as well as for applications that require a small, high-resolution display. The COG IC is the Sitronix ST7565V. This LCD has a FPC interface.

    The ST7565V is a single-chip dot matrix LCD driver that can be connected directly to a microprocessor bus. 8-bit parallel or serial display data sent from the microprocessor is stored in the internal display data RAM and the chip generates a LCD drive signal independent of the microprocessor.

    Technical Information:
    MODULE SIZE41.3 mm x 19.7 mm x 8.1 mm
    VIEW AREA36.1 mm x 9.95 mm
    VOLTAGE3.2 V
    CURRENT60 mA
    DRIVER ICST7565V

    Monochrome Graphic

    Specifications
    Background ColourBlack
    Backlight TypeLED
    Controller TypeNJU6450
    Display Matrix TechnologyFSTN
    Display ModeTransflective
    Display TypeGraphic
    Driver MountingCOG
    External Depth5.5mm
    External Dimensions65.6 x 5.5 x 29.2mm
    External Height29.2mm
    External Width65.6mm
    Illumination ColourWhite
    Interface TypeFPC
    Maximum Operating Temperature               +80°C
    Minimum Operating Temperature-30°C
    Operating Temperature Range-30 → +80°C
    Resolution128 x 32pixels
    Viewing Area Dimensions54.8 x 19.1mm
    Viewing Area Height19.1mm
    Viewing Area Width54.8mm



    Specification PDF Please CLICK HERE

    Thank you for looking, if you have any questions please ask or call us.
