1 x DiodesZetex Diodes Inc FZT849TA NPN Transistor, 7A, 30V, 3 + Tab-Pin SOT-223 - DiodesZetex

roll over the image to zoom in

£0.00
£5.45
RS 215-6600
Earn0
reward points

In stock: 8

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    ES-11D


    DiodesZetex

    Diodes Inc FZT849TA NPN Transistor, 7 A, 30 V, 3 + Tab-Pin SOT-223


    • BMUK Stock No.215-6600
    • BrandDiodesZetex
    • Mfr Part No.FZT849TA
    •
    • You will get ONE transistor
    •
    •






    Product Details

    General Purpose NPN Transistors, Over 1.5A, Diodes Inc








    Bipolar Transistors, Diodes Inc

    Specifications

    Maximum Collector Emitter Saturation Voltage
    0.35 V
    Maximum Operating Temperature
    +150 °C
    Maximum Operating Frequency
    100 MHz
    Number of Elements per Chip
    1
    Maximum Base Emitter Saturation Voltage
    1.2 V
    Length
    6.7mm
    Maximum Collector Base Voltage
    80 V
    Transistor Configuration
    Single
    Brand
    DiodesZetex
    Maximum Collector Emitter Voltage
    30 V
    Package Type
    SOT-223
    Maximum Power Dissipation
    3 W
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -55 °C
    Width
    3.7mm
    Maximum DC Collector Current
    7 A
    Transistor Type
    NPN
    Height
    1.65mm
    Pin Count
    3 + Tab
    Dimensions
    1.65 x 6.7 x 3.7mm
    Maximum Emitter Base Voltage
    6 V
    Minimum DC Current Gain
    30
