1 x Caddock MP930 Series TO-220 Radial Fixed Resistor 100mΩ ±1% 30W 0-+200ppm/°C - Caddock

roll over the image to zoom in

£0.00
£8.99
RS 320-4918
Earn0
reward points

In stock: 38

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS BRA-4H


    Caddock



    Caddock MP930 Series TO-220 Radial Fixed Resistor 100mΩ ±1% 30W 0 → +200ppm/°C


    • BMUK Part # :- 320-4918
    • BrandCaddock
    • Mfr. Part No.MP930-0.10-1%
    •
    •
    • You will get 1 Resistor



    Caddock MP930 Series TO-220 Radial Fixed Resistor 100mΩ ±1% 30W 0 → +200ppm/°C

    Image representative of range



    Product Details

    Caddock 30 W MP916 and MP930 Series Power Film Resistors

    Caddock MP900 Series are a unique family of power resistors. These power film resistors feature a case temperature range of 15 W to 100 W at +25º C.

    Features & Benefits:

    Power film resistors in TO-220 case
    Non-inductive, ideal for frequencies of up to 500 MHz
    Possible to fit a heatsink
    Electrically insulated case (1500 V r.m.s)
    Exposed Ceramic Heat Dissipating Mounting Surface
    Resistance Range of 0.020 Ω to 1 K

    Power at 25°C30W
    Resistance Tolerance±1% (±5% for value 0.02Ω)
    Temperature Coefficient0.02Ω → 0.049Ω: 0 → +300ppm/°C
     0.05Ω → 0.49Ω: 0 → +200ppm/°C
     0.5Ω → 1kΩ: -20 → +80ppm/°C
    Operating Temperature-55°C → +150°C
    Thermal Resistance4.17°C/W
    Limiting Element Voltage250V
    Dielectric Withstand Voltage1500Vrms
    Insulating Resistance10000MΩ
    Height16.26 mm
    Width10.41 mm
    Lead Length (Below Standoff)11.43 mm
    Pin Spacing5.08 mm



    Specifications


    Resistance100 mΩ
    Power Rating30W
    Tolerance±1%
    TechnologyPower Film
    SeriesMP930
    Case StyleMoulded
    Temperature Coefficient0 → +200ppm/°C
    Termination StyleRadial
    Package/CaseTO-220
    Dimensions10.41 x 3.18 x 19.56mm
    Length10.41mm
    Depth3.18mm
    Height19.56mm
    Maximum Temperature Coefficient+200ppm/°C
    Minimum Operating Temperature-55°C
    Minimum Temperature Coefficient0ppm/°C
    Maximum Operating Temperature+150°C
    Lead Pitch5.08mm
