1 x C & K Rotary Switch MH00L1NZQD 6 Way Solder 28V dc 125V ac, 250 mA @ 28V dc - C & K
roll over the image to zoom in
£0.00
£49.99
RS 161-5114
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 8H
C & K
C & K Rotary Switch MH00L1NZQD, 6 Way, Solder, 28V dc 125V ac, 250 mA @ 28V dc
- BMUK Part # :-161-5114
- BrandC & K
- Mfr. Part No.MH00L1NZQD
-
- You will get 1 Rotary Switch
Product Details
Miniature Rotary Switches
These half-inch rotary switches are designed for use in a wide variety of application including test equipment, industrial equipment and medical equipment. For durability they feature a stainless steel actuator and non-shorting contacts.
Metal bodied rotary switches with 30° indexing for panel mounting
Offered in a non-stop rotating version which can be set from 2 to 6 or 12 positions, depending on the model, by use of the stop ring supplied
Available in single pole 12-way (161-5108) and double pole 6-way (161-5114) versions
Break before make contacts
Panel cut-out: Ø6.35mm
Shaft: Ø3.17mm; Length: 9.53mm
PCB and Panel Mounting Combined
Specifications
| Contact Configuration | DP | |
| Contact Current Rating | 250 mA @ 28 V dc | |
| Number of Switch Positions | 6 | |
| Number of Contacts | 2 | |
| Voltage Rating | 28 V dc, 125 V ac | |
| Depth | 13.34mm | |
| Width | 13.34mm | |
| Mounting Type | Panel Mount | |
| Terminal Type | Solder | |
| Contact Material | Silver Plated Copper Alloy | |
| Height | 31.37mm | |
| Maximum Operating Temperature | +85°C | |
| Angle of Throw | 30° | |
| Minimum Operating Temperature | -30°C | |
| Case Material | Zinc Alloy |
